3-640426-2
Manufacturer:
TE Connectivity
Mfr.Part #:
3-640426-2
Datasheet:
Description:
Headers and Wire Housings Free Hanging Receptacle Number of Positions:2 Pitch:3.9624 mm
| Parameter | Value |
|---|---|
| Length | 7.92 mm |
| Termination | IDC |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Voltage Rating (AC) | 600 V |
| Number of Pins | 2 |
| Height | 9.02 mm |
| Packaging | Bulk |
| Voltage Rating | 600 V |
| Depth | 9.02 mm |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Pitch | 3.96 mm |
| REACH SVHC | No SVHC |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | CuSn |
| Pitch | 3.9624 mm |
| Current Rating | 7 A |
| Flammability Rating | UL94V-2 |
| Approvals | CSA |
| Orientation | Right Angle |
| Operating Supply Voltage | 600 V |
| Lifecycle Status | Production (Last Updated: 4 days ago) |
| Color | Orange |
| Gender | Socket (Female) |
| Number of Contacts | 2 |
| Connector Type | Receptacle |
| Wire/Cable Gauge | 18 AWG |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Housing Material | Nylon |
| Wire/Cable Type | Discrete |
| Fastening Type | Ramp |
| Circuit Application | Power |
| Connector System | Wire-to-Board |
| Contact Style | Socket |
| Contact Resistance | 3 mΩ |
| Max Voltage Rating (AC) | 600 V |
| Contact Current Rating | 7 A |
| Housing Color | Orange, White |
| Plating | Tin |
| Insulation Diameter | 2.413 mm |
| shrouded | No |
| Plating Thickness | 80 µm |
| Contact Gender | Female |
| Number of Power Positions | 2 |
| Underplate Material | Nickel |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 4 days ago) |
| Sealable | No |
| Contact Retention | With |
Stock: 10625
Distributors
pcbx
pcbxUnit Price$0.18809
Ext.Price$0.18809
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.18809 | $0.18809 |
| 10 | $0.16158 | $1.61580 |
| 50 | $0.14867 | $7.43350 |
| 100 | $0.13679 | $13.67900 |
| 500 | $0.12330 | $61.65000 |
| 1000 | $0.11114 | $111.14000 |
